All in English& Imperial Unit.全部使用英文和英制单位
-
Are part dimensions to print plus shrink?请检查内模尺寸有否乘缩水?
-
All wires protected from sharp corners?凡有电线通过的角位要改为R角,是否完成?
-
All replaceable components must be standard components.所有替换的元件必须是标准件。
-
Add shot counter?是否加啤塑总计器?
-
A complicated mould with thorough design consideration to overcome the numerous design contraints.
一个复杂的模具,设计经过周详考虑,成功地克服了各种设计上的限制。
-
All moving components should use hardened steel : all slides should be installed with hardend or lubricated alloy wear plates and gibs, and with positive slide retainer.
所有移动的零件应使用硬钢料,行位必须用硬垫板和硬线条,而且必须有限位及定位锁。
-
BOM including water fittings,ejectors&custom components.BOM的内容应包含运水接头,顶针和自制的零件.
-
BeCu for lifters if w/o water circuits。若没有运水回路,斜顶为铍铜。
-
Corresponding components mirrored at core&cavity对应的部件在前、后模平面视图中镜像
-
-
Check polish for line of draw finish?有否省光就出模?
-
Core pull slot mechanism installed and O.K.
-
Crane capacity and loading clearance.模具须用多大吊机才可搬动。
-
Conduct moldflow &mold warp analysis.经流道及变形电脑模拟分析。
-
Component and/or 3D mould design drawing.散件图或3D模具图
-
Cooling less important when dimensions are not important.若尺寸不重要,适量冷却也可。
-
Combine a traditional 4 cavity edge gate and a 4 cavities reverse gate mould which help to double the moulding capacity and reduce production cost.
将一个标准四模腔大水口模具与一个四模腔倒转大水口模具结合成为一套可于同一大小的注塑机,生产量可增加一倍的层板模具,并且可降低成本。
-
Can be seperated into two individual moulds for moulding in two different mould shops.
此模具最大的特式是,可将模具分开变成两套,在不同地方生产,增加生产的灵活性。
-
Consists of all standard mould components which facilitates mould maintenance.
由于全套模具均利用模具标准零件制成,在维修及换零件上比较方便。
-
Die draw called out出模方向的标示
-
Dimension all the opening , travel & clearance标出前、后模距离,滑动部件滑动距离和塑件脱离的位置
-
DME egr. Water fittings recessed and marked?是否使用DME运水接头及编号?
-
Delivery right side up , or in two halves?开箱后是否容易吊出模具及是否分开前/后模运输?
-
Eyebolt size and balance in 2 sides吊模孔尺寸,平衡,4边都要有
-
Ejection stroke & slide, lifter travel dimensioned出行程、行位、斜顶行程的标注。
-
Ejection study if lifter adopted若有斜顶,做出分析。
-
Ejection extended at the most顶出到极限位置
-
Ejector guide pins installation .顶针导柱的安装。
-
Eyebolts for inserts more than 50lbs.重量大于50lbs的镶件必须要有吊模孔。
-
Edge gate or sprue gate requiring secondary operation acceptable.边缘型或直入型水口都可以接受。
-
4 point in HRC different to lifters contacting or cavity steel.斜顶和与其接触的内模或镶件在硬度上有4度的差别(HRC)。
-
4X size section , dimensioned to reflect the actual size.水口及水口顶针的4倍放大视图,按实际尺寸标注。
-
General ,safety and handling 常规、安全和搬运要求
-
Guided ejection recommended for mould above 100 tons clamp capacity, ejector pins of 1.5mm or smaller, or ejector stroke longer than 50mm.
建设模具用于锁模力超过100吨的注塑机,或有1.5mm以下的顶针或顶出行程超过50mm时,应装上顶针板导柱。
-
Guide pin cleared and vented?边钉插入模板有否顶着及加疏气空?
-
Hot manifold wired to print and checked? 热咀电线接位有否编号?
-
Horn pin clearance hole?斜边与行位有否空间?
-
Hydraulic actuated slide together with electrical limit switch.
行位采用油压推动,配合安全电制。
-
Heaters fitted+0.002/-.000, leads tagged and connected to terminal.热嘴装配,电线源头、尾有否安装稳固。(+0.002/.000)
-
Inserts keyed and numbered to prevent incorrect assembly.镶件定位和编号以防止不正确的组装。
-
Jaw angle 3 deg.more than angle pins(<25 degree).斜面角度要比行位斜边角度大3度(<25度)。
-
Keep enough space to run waterline at slide /lifter/major inserts.在行位、斜顶、主要镶件处保留足够位置(空间)布置水槽。
-
Lifter angle less than 15 degree.斜顶角度小于15度。
-
Lifter rods dia, less than 1".斜顶杆直径不能少于1"。
-
Limit switch in tact and protected.是否已安装限位制?
-
Moldbase and steel dimensioned模坯和钢料号的标注
-
Minimum 5 deg.for shut-off.斜顶镶件最小5度插穿。
-
Mechanism for sequence动作机构是否正确?
-
Mold safety straps installed and painted red?是否已安装安全带及喷上正确颜色在模坯上?
-
Mould flow and simulation should be carried out for the best gate location, filling analysis, pressure distribution and heat distribution.
适宜应用模拟的模具注塑过程,注射分析、压力分布及温度分布以确定最佳入水位置、流道尺寸和疏气位置等。
-
